The Unikeys x BSUN Waves (rail bottom-out) and Wuque Studio WS Jade switches are both standard MX mechanical switches of the linear breed. They both feature POM top housing, POM bottom housing, standard stem shape, 2 mm pre-travel, however, they come with different stem material (Y3X vs UPE), spring (22 mm single-stage nickel-plated vs 18 mm two-stage), actuation (48 g vs 50 g), bottom-out force (55 g vs 60 g), total travel (4 mm vs 3.60 mm). That said, they are only slightly similar. Let's check out this side-by-side specs rundawn with details, availability -- and even current prices -- to figure out which one fits you the best!
The Unikeys x BSUN Waves (rail bottom-out) is a linear standard MX mechanical switch with POM top housing, POM bottom housing, and Y3X stem (standard shape). It features a 22 mm single-stage nickel-plated spring. The 48g actuation occurs at 2mm. The 55g bottom-out occurs at 4mm. Factory lubing? Yes! Designed by Unikeys. Manufactured by BSUN. | The Wuque Studio WS Jade is a linear standard MX mechanical switch with POM top housing, POM bottom housing, and UPE stem (standard shape). It features a 18 mm two-stage spring. The 50g actuation occurs at 2mm. The 60g bottom-out occurs at 3.60mm. Extra: Light diffuser. Factory lubing? Yes! Designed by Wuque Studio. |
|
|
| Name | Unikeys x BSUN Waves (rail bottom-out) | Wuque Studio WS Jade |
|---|---|---|
| Type | linear | linear |
| Footprint | 5-pin | 5-pin |
| Top housing | POM | POM |
| Bottom housing | POM | POM |
| Stem material | Y3X | UPE |
| Stem shape | standard | standard |
| Spring | 22 mm single-stage nickel-plated | 18 mm two-stage |
| Actuation | 48 g | 50 g |
| Bottom-out | 55 g | 60 g |
| Pre-travel | 2 mm | 2 mm |
| Total travel | 4 mm | 3.60 mm |
| Lube | Factory lubing? Yes! Factory lubed. The upper section of stem sliders is lubed only to avoid lube pooling issues. Springs are lubed with dry film. | Factory lubing? Yes! |
| Designer | Unikeys | Wuque Studio |
| Manufacturer | BSUN | - |
By tracking prices and in-stock status of 30+ well-known keyboard stores worldwide, we can state that the Unikeys x BSUN Waves (rail bottom-out) is not available at the moment, while the Wuque Studio WS Jade can be found in 5 stores.
Clicking the links below take you to some notable keyboard shops offering Unikeys x BSUN Waves (rail bottom-out) and Wuque Studio WS Jade switches. When accepted, the prices indicated already include the discount - use the KBDNEWS coupon code at checkout to claim your saving!
Prices, discounts, and stock status are checked regularly; however, changes since the last update cannot be ruled out. Everything here is for informational purposes only. Check the product pages for the latest prices!
Comments on Unikeys x BSUN Waves (rail bottom-out) switches | Comments on Wuque Studio WS Jade switches |
The Unikeys Waves switches are one of BSUN's few rail bottom-out full travel switches. Both the stem and the housings are manufactured using BSUN's most recent moldings; The Stem wobble is minimal while smoothness is guaranteed. Each keystroke is precise and pleasant. The stem comes with the same material as the Jade Rosales switches, and the housing is fully made of POM. Such material choices make the overall sound profile medium-pitched with a medium volume. They are not as loud and clacky as HMX Snow Crash switches but not muted and dull either. Expect them to be a rail bottom-out switch that comes with the classic BSUN sound signature. To prevent the lube pooling issue, only the upper section of the stem sliders are lubed with 205g0. Stem legs and the lower section of stem sliders are dry. The lube on the stem sliders will spread evenly after use and become a thin coat that covers the sliders. Springs are lubed with dry-film. Disclaimer: As the Waves switches only come with lubed stem sliders, and the stem legs and leaf are dry, there might be some slight noise when the switches actuate (Stem legs making contact with the leaf). Applying a very thin coat of lube on either the stem legs or the leaf will help eliminating the noise – Unikeys. | The Wuque WS Jade Switches are linear switches with a particular metallic contact point at maximum pressure. They take the popular Morandi switch and add metal inserts on both the bottom of the stem and the contact point of the bottom of the casing for a uniquely smooth typing experience – coffeekeys. Wuque WS Jade Switches are linear switches with a unique, metallic bottom-out. It takes the popular Morandi switch and adds metal inserts on both the stem bottom and the bottom housing contact point for a unique and smooth typing experience – DiviniKey. |
