The Gateron Quinn and Wuque Studio WS Brown switches are both standard MX mechanical switches of the tactile breed. They both feature Nylon top housing, Nylon bottom housing, POM stem material, 2 mm pre-travel, however, they come with different stem shape (standard vs partial box), spring (22 mm two-stage gold-plated vs 22 mm two-stage), (59 g vs 63 g), actuation (50 g vs 45 g), bottom-out force (67 g vs 55 g), (0.50 mm vs 1 mm), total travel (3.40 mm vs 3.80 mm). That said, they are only slightly similar. Let's check out this side-by-side specs rundawn with details, availability -- and even current prices -- to figure out which one fits you the best!
The Gateron Quinn is a tactile standard MX mechanical switch with Nylon top housing, Nylon bottom housing, and POM stem (standard shape). It features a 22 mm two-stage gold-plated spring. The tactile bump is 59g at 0.50mm. The 50g actuation occurs at 2mm. The 67g bottom-out occurs at 3.40mm. Factory lubing? Yes! Manufactured by Gateron. | The Wuque Studio WS Brown is a tactile standard MX mechanical switch with Nylon top housing, Nylon bottom housing, and POM stem (partial box shape). It features a 22 mm two-stage spring. The tactile bump is 63g at 1mm. The 45g actuation occurs at 2mm. The 55g bottom-out occurs at 3.80mm. |
|
|
| Name | Gateron Quinn | Wuque Studio WS Brown |
|---|---|---|
| Type | tactile | tactile |
| Footprint | 5-pin | 5-pin |
| Top housing | Nylon | Nylon |
| Bottom housing | Nylon | Nylon |
| Stem material | POM | POM |
| Stem shape | standard | partial box |
| Spring | 22 mm two-stage gold-plated | 22 mm two-stage |
| Tactile force | 59 g | 63 g |
| Actuation | 50 g | 45 g |
| Bottom-out | 67 g | 55 g |
| Tactile bump position | 0.50 mm | 1 mm |
| Pre-travel | 2 mm | 2 mm |
| Total travel | 3.40 mm | 3.80 mm |
| Lube | Factory lubing? Yes! | unknown |
| Designer | - | - |
| Manufacturer | Gateron | - |
By tracking prices and in-stock status of 30+ well-known keyboard stores worldwide, we can state that the Wuque Studio WS Brown is not available at the moment, while the Gateron Quinn can be found in 9 stores.
Clicking the links below take you to some notable keyboard shops offering Gateron Quinn and Wuque Studio WS Brown switches. When accepted, the prices indicated already include the discount - use the KBDNEWS coupon code at checkout to claim your saving!
Prices, discounts, and stock status are checked regularly; however, changes since the last update cannot be ruled out. Everything here is for informational purposes only. Check the product pages for the latest prices!
Gateron Quinn force curve | Wuque Studio WS Brown force curve |
|
|
