Tag: PCB (806 entries)
The MX Unsaver is a custom keyboard and numpad by nearestexit: inspired by the vintage IBM "Unsaver".
An open-source wireless split keyboard by yyevax: Xavient is available both in 36-key or 42-key configs.
A 36-key monoblock split based on the Yolochka: Yolochka Remastered by turtle_bazon – with PCB.
A 52-key wireless split keyboard: Phanny by zackattack.
The wireless Ashwing64 by Flexyjerkov is a 64-key monoblock keyboard with exposed diodes.
MagoSaronno's split Keyther is a Cantor-derivative – halves connected by an Ethernet cable.
The wireless Cheap03xD is an affordable open-source split by Lander03xD.
An open-source Hall-effect unibody split keyboard: TrueStrike42 by Choi Byungyoon.
Rafael Furlanetto Casamaximo released his wireless 65% voidPointer with exposed diodes.
A diodeless unibody split by Peter J. A. Cock: Slump52 with number pad.
A clean and simple open-source split keyboard by Terence-1.
An RP2040-based modular macropad system by Juho T.: the Suutari20 using TRRS sockets and jacks.
Gareth Gummow's ortholinear Tentacle is using the author's SquidHID firmware.
The next iteration of Chris Trotter's ArcBoard is here. Mk20 comes with a lot of improvements.
An Atreus-inspired monoblock keyboard by Mae Pugin: the wireless KaSe with OLED.
The DYA Dash is a nice wireless split project by Cormoran: low-pro, touch sensors, trackball.
Yuburoll's Boardloaf is an open-source 36-key split keyboard with MX keys.
A Bluetooth diode-free 36-key ergonomic keyboard PCB by Peter Cock: Gamma Omega Hesse – using graph theory.
Yuburoll's modubu is a semi-staggered 38-key split keyboard – made for Korean layout.
Chris Lo released his loongcat40, a gasket-mounted offset ortho keyboard featuring a nice OLED.
Charading's Shego75HE, an open-source 75% Hall-effect keyboard, runs QMK.
A 100%-ish keyboard with split thumb clusters – Mist by Modern Hobbyist.
A Totem-fork by Atila M. Schrieber – with an extra pinky key.
A 36-key open-source split: the Sweep Squared by Zexx37 with great switch support.
Yuburoll's KeeNoard is a 38-key split keyboard with rotary encoder and multiple center key, with only one RP2040 Zero board.
