Tag: PCB (507 entries)

Triboard

Tarneo shared a small and portable sub-10x10 cm ergo split called Triboard.

Swepp

Sebastian Stumpf's Swepp is a splayed Sweep, a split keyboard with 34 keys.

Kazik

Kazik is a cute 30% keyboard by monokēēbs – with versatile PCB, XIAO RP2040, and Japanese duplex matrix!

Starship Bubu & OmegaSupreme

Protieusz shared a standalone trackball along with an open-source trackball module: Starship Bubu-01 and OmegaSupreme.

Proteus67

A displaced ortho by James Gzowski: Proteus67 – with encoder.

HillSideView

Shay's HillSideView is a derivative of the original Hillside – with nice!view and more changes.

Storyboard

Cbskii's Storyboard is a 5x12 hotswap ortholinear keyboard with an e-ink display.

Span keyboard

Span is a split with trackpoint support by Idan of holykeebs – in the footsteps of the GergoPlex.

Yurigs80

Patrick Ryan shared his Yurigs80, a 84-key keyboard with Pi Pico and encoder.

Corne Chocoflan

Hai Nguyen of ergomech.store shared his Corne Chocoflan, a low-pro Corne variant optimized for wireless use.

Corne Xiao

Released by FrictioN, this Corne Xiao is a modified, wireless version of foostan's Corne keyboard.

Corne GLP

BeeKeeb's Leo introduced the open-source Corne GLP, a variant specifically designed for Gateron low-profile hotswap sockets.

SpUnLy58 1.2

Giraffasax updated the SpUnly58. Iteration V1.2 of this monoblock split comes with adjusted spacing, splay, and stagger.

Rolio 0.9

MickiusMousius shared the updated Rolio 0.9, a premium split keyboard in a nice aluminum chassis.

MidEvil

Ming-Gih Lam is back with a new project: MidEvil is an orthoish/Alice monoblock split keyboard with a numpad in the middle.

Abomination

Sebastian Stumpf shared the files of his Abomination, a classy split keyboard with trackpad and some splay.

Större

STHLM kb announced Större, an easy-to-build 75% keyboard kit with exposed diode cluster and using only through-hole components.

PUR

Sergei shared his PUR keyboard, an ortholinear one with offset spacebar and bent metal sheet case.

Crabapplepad

Sergei Silnov's Crabapplepad is a minimalistic, ultra low-pro foldable split keyboard with X switches.

Wave keyboard

Etienne Collin's Wave is a reversible split Ferris/Sweep derivative with Mini DIN 4 connectors.

Mün 2

It turned out that RGBKB's Mün 2, mentioned last week, is now open hardware. Check out the repo.

Chrumm 1.0

Severin Meyer published Chrumm, a gorgeous unibody split with flexible PCB and fixed tenting.

Dilemma Max

The Dilemma Max is an ergo split keyboard by Bastardkb – with number row and trackpad.

Alien Invader

Protieusz made Alien Invader, a PCB with on-board RP2040 for Joe Scotto's originally handwired Scotto Invader.

Yakamoz

Yakamoz is a 50-key ortholinear keyboard by Özkan Çelik – it comes with an OLED display, buzzer, optional trackball and RGB underglow.

×
