Red Cedar split

The Red Cedar is a well-documented Dactyl-like split by Tim Wenger – with PS2 buttons.

KBD.news
Published January 28, 2025
Creators! Feel free to tip me off about your keyboard related projects to bring them to 140K readers.

The Red Cedar, shared by Tim Wenger aka WesternRedCdar, is a well-documented Dactyl-like split with PS2 buttons and Nintendo Switch joystick – inspired by Tewtham's TypeSafe.

This keyboard was designed to look a bit like a red cedar tree – it has a green outer shell with a red cedar bark tree stem (copper PCB) showing through :). The PS2 buttons were just for fun – but they do allow you to comfortably press Control and Alt at the same time with one thumb – Tim.

Pic:

Features

  • 46 keys?
  • MX, handwired, plus PS2 switches
  • RP2040 Pro Micro controller
  • keywell
  • QMK

Pic:

Resources

Excellent documentation with files, BoM, build guide, tips, etc:

Do you like this post? Share, donate, subscribe, tip me off!

Published on Tue 28th Jan 2025. Featured in KBD #185 (source).
